Description
Barksdale KD2510 is a cab-mount air-suspension height control / leveling valve with the P3 linkage kit, used on Freightliner cab air-spring assemblies (18-58444-000) and other Class 8 cab-suspension installations. Shear-Seal® spool design holds set ride height through load and road inputs and bleeds excess air via the integrated dump path during loading.
Specifications
| Manufacturer | Barksdale |
|---|---|
| Part Number | KD2510 (BKS KD2510) |
| Part Type | Cab Air Suspension Height Control / Leveling Valve |
| Mount Style | Cab-mount with P3 linkage kit |
| Internal Design | Shear-Seal® spool |
| Approx. Dimensions | 11 in L x 4 in W x 4 in H (kit packaging) |
| Warranty | 1 year unlimited mileage (Barksdale) |
Kit Includes
- Barksdale KD2510 height control valve body
- P3 cab-mount bracket
- Linkage rod and pivot hardware
Cross References
This height control valve replaces or is equivalent to the following part numbers:
- Barksdale: KD2510, BKS KD2510, BKS-KD2510
- Freightliner / Alliance: 18-58444-000
- Also known as: 26721SS, MPGS-26721, ATX26721, ATP26721, GTS26721, GTPKD2510, KD2510C8T, KD2510-RC, KD2510HTP, VIPKD2510, PSKD2510, BKRKD2510, BKR-KD2510, S KD2510
Applications
This cab-mount height control valve fits Class 8 cab air-suspension installations, including:
- Freightliner Cascadia and M2 cab air-suspension (18-58444-000 application)
- Other Class 8 cab installations using the Barksdale KD2510 cab-mount valve with P3 linkage
Verify your existing valve mount, linkage geometry, and air port sizing before ordering. The KD2510 controls cab air-spring ride height; do not substitute for a chassis or trailer leveling valve without verifying port and linkage compatibility.
