Description
The Baldwin CA5369 is a Channel Flow air filter that replaces Motorcraft FA1886 and Ford 7C3Z-9601-B on 2008-2010 Ford Super Duty trucks with the 6.4L Power Stroke V8. Its conical channel-flow design routes air straight through the element, dropping intake restriction while a radial seal locks out unfiltered bypass at the housing.
Specifications
| Manufacturer | Baldwin |
|---|---|
| Part Number | CA5369 |
| Part Type | Channel Flow Air Filter Element |
| Length | 8.72 in (221.5 mm) |
| Outside Diameter (small end) | 6.03 in (153.2 mm) |
| Outside Diameter (large end) | 11.88 in (301.6 mm) |
| Seal | Radial seal (gasket attached) |
| Media | Pleated cellulose-blend with rigid plastic frame |
| Engine Compatibility | Ford 6.4L Power Stroke V8 diesel |
Cross References
This filter replaces or is equivalent to the following part numbers:
- Ford: 7C3Z-9601-B
- Motorcraft: FA1886
- Fleetguard: AF27687
- Donaldson: P613522
- WIX: 49886
- NAPA: 9886
- Fram: CA10270
- Purolator: A55697
- Hastings: AF2402
- Luber-Finer: LAF2886
- MANN+HUMMEL: C32034
- Champion: LAF2886
- Carquest: 83886
- HiFi Filter: SA16608
Applications
This air filter fits the following:
- Ford 6.4L Power Stroke V8 diesel (2008-2010)
Representative vehicles using this engine:
- Ford F-250 / F-350 / F-450 / F-550 Super Duty (2008-2010)
- Ford F-53 motorhome chassis with the 6.8L V10 (2011) — same air-box pattern
Verify air-box latch arrangement and existing filter dimensions before ordering to confirm fitment.
