Description
Automann 562.458 is a 45-degree angled spring-loaded mud flap hanger kit, sold as a pair of 30 in black painted-steel hangers with 2.000 in center-to-center bolt spacing. The internal spring keeps each flap aligned and prevents sway when the truck is unloaded or in heavy crosswinds. Universal fitment for Class 8 trucks and trailers spec’d for 2 in bolt-pattern brackets.
Signs You Need New Mud Flap Hangers
- Mud flaps dragging, sagging, or hanging unevenly
- Cracked, bent, or corroded hanger arms from road debris or salt
- Excessive flap swing contacting the tire or frame
- Missing or damaged splash guard mount flagged at DOT inspection
Specifications
| Manufacturer | Automann |
|---|---|
| Part Number | 562.458 |
| Part Type | Mud Flap Hanger Kit, Spring-Loaded |
| Hanger Geometry | 45-degree angle |
| Length | 30 in |
| Mounting Bolt Spacing | 2.000 in center-to-center |
| Finish | Black painted steel |
| Frame Seat | No |
| Conspicuity Tape | No |
| Kit Weight | 24.6 lb |
| Quantity | 2 hangers per kit (1 pair) |
Kit Includes
- Spring-loaded mud flap hanger arms (qty 2) — 45-degree, 30 in, black
Related Automann Hanger Kits
Automann offers several mud flap hanger configurations. Verify your bolt spacing and style preference before ordering:
- 562.418: 45-degree, chrome, 1.125 in bolt spacing, with conspicuity tape
- 562.457: 45-degree, black, 1.125 in bolt spacing, no tape
- 562.458: 45-degree, black, 2.000 in bolt spacing, no tape (this kit)
- 562.411: Straight, black, 1.125 in bolt spacing, with conspicuity tape
Applications
Universal fit for Class 8 trucks and trailers with 2.000 in center-to-center mud flap bracket bolt patterns:
- Freightliner Cascadia, Columbia, Century, FLD
- Kenworth T680, T880, W900, T800
- Peterbilt 389, 579, 567, 379
- Volvo VNL, VNR
- Mack Anthem, Pinnacle, Granite
- International LT, LoneStar, ProStar
- Western Star 4900, 5700XE
Measure your existing mounting bracket center-to-center before ordering. This kit uses 2.000 in bolt spacing — not compatible with 1.125 in or 2.5 in patterns.
