Description
Midland Industries 28027 forged yellow brass pipe tee joins three 1/2 in. female NPTF lines at a 90° branch. Used to feed a parallel circuit off an NPTF run on heavy-duty truck pneumatic, fuel, and fluid plumbing — air-brake manifolds, gauge clusters, and accessory tees on tank and chassis-mounted plumbing.
Specifications
| Manufacturer | Midland Industries |
|---|---|
| Part Number | 28027 |
| Part Type | Pipe Tee (FIP × FIP × FIP) |
| Connection | 1/2 in. female NPTF on all three branches |
| Material | Yellow brass (forged) |
| Length | 1.09 in |
| Weight | 0.430 lb |
| Standards | SAE J476 / J1453 (NPTF Dryseal) |
Cross References
This part replaces or is equivalent to the following part numbers:
- Also known as: 016004, 06101-08, 101-8, 101-D, 101A-D, 11536-204, 13Y897, 16004, 201800, 2203P-8, 23700-8, 23700X8, 3700X8, 3700X8-CT, 440110-131280, 50785K74, 88014, BP101-8, S203-8, X101-D
Applications
Used on heavy-duty truck and mobile equipment NPTF systems:
- Air-brake manifolds, gauge plumbing, and tee outlets
- Fuel-system test, pressure-tap, and gallery ports
- Pneumatic instrument-panel, HVAC, and chassis-air circuits
- Hydraulic auxiliary plumbing where NPTF is used (low-pressure return / pilot)
Use NPTF-compatible thread sealant rated for the system fluid and pressure.
